SEUIC (Dongji) / Touch mobile terminals
CRUISE2 5GC: Touch mobile terminals
CRUISE2 5GC is listed in the touch mobile terminals portfolio for touch-first mobile data capture. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: touch-first warehouse, retail, logistics and field applications
- Display
- 6.0-inch color HD (1440*720); typical value 400nit
- Scan |
- X3PC(HD)/X3PC(MR) 1D/2D scanning engine
- power supply
- User-removable 5000mAh (19.25Wh) lithium-ion rechargeable battery; hot-swappable battery supported
- Sealing level |
- IP68 sealing level (including battery)
- network connection
- WWAN 5G、WLAN
- weight
- 280±5g/9.88±0.18oz (including battery)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where CRUISE2 5GC fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and logistics applications
- Retail inventory and store operations
- Field inspection and service
Key capabilities
- A full-touch mobile terminal entry; scan engine, network, OS and battery options require model-level confirmation.
- Portfolio fit: touch-first warehouse, retail, logistics and field applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 6.0-inch color HD (1440*720); typical value 400nit |
|---|---|
| touch screen | Capacitive touch, supports glove touch/wet hand operation/double-click to wake up |
| CPU | | MTK8863T octa-core, 2.4GHz |
| operating system | | Android 14.0, support upgrade to Android 16.0 in the future |
| Memory | | 4GB RAM/64 GB UFS Flash; 8 GB RAM/128 GB UFS Flash |
| Operating temperature | | -20℃ to 55℃/-4℉ to 131℉ |
| Storage temperature | | -40℃ to 70℃/-40℉ to 158℉ (battery not included) |
| Electrostatic discharge (ESD) | | ±15kV air discharge, ±8kV direct discharge |
Data capture
| Interactive Sensor Technology | | Gravity sensor, light sensor, distance sensor |
|---|---|
| Scan | | X3PC(HD)/X3PC(MR) 1D/2D scanning engine |
| Near field communication (NFC) | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards) |
Connectivity
| SIM card | Nano SIM card*2 (dual SIM card dual standby) |
|---|---|
| network connection | WWAN 5G、WLAN |
| Interface/communication | Waterproof Type-C USB interface; supports USB 2.0 HighSpeed; supports OTG; supports fast charging |
| GPS | | | GPS+GLONASS+Beidou+Galileo; support a-GPS; L1 single frequency |
| Wireless LAN | IEEE 802.11 a/b/g/n/ac/d/e/h/i/j/k/r/v/w (2.4G/5G dual-band WIFI) |
Power and physical
| weight | 280±5g/9.88±0.18oz (including battery) |
|---|---|
| power supply | User-removable 5000mAh (19.25Wh) lithium-ion rechargeable battery; hot-swappable battery supported |
| button | Volume up/down buttons; power button; two dedicated scan buttons; programmable button for push-to-talk or other purposes |
Environmental
| Humidity | | 5% to 95% RH without condensation |
|---|---|
| Sealing level | | IP68 sealing level (including battery) |
| Roll Specs | | Withstands 1,000 drops from 1.6 feet/0.5 meters at room temperature without protective case |
| Drop specifications | | Withstands a 2 meter (6.56 ft) drop to tile on concrete when terminated only |
Other configuration
| size | 161mm (length) × 77mm (width) × 13.6mm (height); · 6.34 inches (length) × 3.03 inches (width) × 0.54 inches (height) |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports up to 256GB |
| notify | Alert sound; vibration (tactile feedback); multi-color LED light indication |
| keyboard | On-screen keyboard |
| Audio | Built-in single speaker (2W); two microphones with noise reduction function; supports Type-C headphones |
| Image acquisition | Front 5 million pixels; rear 13 million pixels (auto focus) |
| radio frequency band | GSM Quad Band(850/900/1800/1900Mhz); WCDMA B1, B2, B5, B8; CDMA 1x/EVDO BC0; TDD-LTE B34, B38, B39, B40, B41; FDD-LTE B1, B3, B5, B7, B8, B20, B28; 5G N1, N3, N8, N28, N41, N78, N79; supports VoNR; supports SA/NSA dual mode (Sub6G) |
| data rate | 5 GHz: 802.11a/n/ac – 20 MHz, 40 MHz, 80 MHz – up to 433.3 Mbps · 2.4 GHz: 802.11b/g/n – 20 MHz – up to 72.2 Mbps |
| working channel | Channels 1–13 (2412–2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 · Channels 36–165 (5180–5825 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 · Channel bandwidth: 20 MHz, 40 MHz, 80 MHz · Actual operating channel/frequency and bandwidth are subject to regulatory rules and certification agencies |
| Security and encryption | Security modes: legacy3, WPA, WPA2, 802.1X · Encryption: WEP40/WEP104, TKIP and AES · Authentication: EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, EAP-PWD, FIPS 140-2 |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm scan handle, spare battery, cradle, protective case and MDM or application enrollment needs.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make CRUISE2 5GC part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
