SEUIC (Dongji) / Touch mobile terminals
CRUISE2 5G Pro: Touch mobile terminals
CRUISE2 5G Pro is listed in the touch mobile terminals portfolio for touch-first mobile data capture. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: touch-first warehouse, retail, logistics and field applications
- Display
- 6.0-inch color full HD (2160*1080); typical value 450nit
- Scan |
- HS7 1D/2D Scan Engine · X3P(SR) 1D/2D Scan Engine
- power supply
- User-removable 5000mAh (19.25Wh) lithium-ion rechargeable battery; hot-swappable battery supported
- Sealing level |
- IP68 sealing grade (including battery) / IP68 sealing grade (without battery)
- network connection
- WWAN、WLAN
- weight
- 280±5g/9.88±0.18oz (including battery)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where CRUISE2 5G Pro fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and logistics applications
- Retail inventory and store operations
- Field inspection and service
Key capabilities
- A full-touch mobile terminal entry; scan engine, network, OS and battery options require model-level confirmation.
- Portfolio fit: touch-first warehouse, retail, logistics and field applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 6.0-inch color full HD (2160*1080); typical value 450nit |
|---|---|
| touch screen | Capacitive touch, supports glove touch/wet hand operation/double-click to wake up |
| CPU | | Qualcomm 4490 octa-core, 2.4GHz |
| operating system | | Android 13.0, support upgrade to Android 18.0 in the future |
| Memory | | 4GB RAM/64 GB UFS Flash; 8 GB RAM/128 GB UFS Flash |
| Operating temperature | | -20℃ to 50℃/-4℉ to 122℉ |
| Storage temperature | | -40℃ to 70℃/-40℉ to 158℉ (battery not included) |
| Electrostatic discharge (ESD) | | ±15kV air discharge, ±8kV direct discharge |
Data capture
| Interactive Sensor Technology | | Gravity sensor, light sensor, distance sensor, electronic compass, gyroscope, barometer (optional function) |
|---|---|
| Scan | | HS7 1D/2D Scan Engine · X3P(SR) 1D/2D Scan Engine |
| Near Field Communication (NFC) | | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards) |
Connectivity
| SIM card | Nano SIM*1+eSIM*1 |
|---|---|
| network connection | WWAN、WLAN |
| Interface/communication | Waterproof Type-C USB interface; supports USB3.0 HighSpeed; supports OTG (does not support display); supports fast charging |
| GPS | GPS, Beidou, GLONASS three-in-one, supports a-GPS; · Dual-frequency GPS (L1+L5) |
| wireless lan radio | IEEE 802.11a/b/g/n/ac/d/h/i/k/r/v/ax ；Wi-Fi 6E（801.11ax）；2x2 MU-MIMO |
Power and physical
| weight | 280±5g/9.88±0.18oz (including battery) |
|---|---|
| power supply | User-removable 5000mAh (19.25Wh) lithium-ion rechargeable battery; hot-swappable battery supported |
| button | Volume up/down buttons; power button; two dedicated scan buttons; programmable button for push-to-talk or other purposes |
Environmental
| Humidity | | 5% to 95% RH without condensation |
|---|---|
| Sealing level | | IP68 sealing grade (including battery) / IP68 sealing grade (without battery) |
| Roll Specs | | Withstands 1,000 tumbles from 1.6 ft./0.5 m at room temperature without case |
| Drop specifications | Withstands a 1.5 m (5 ft) drop to tile on concrete when terminated only |
Other configuration
| size | 161mm (length) × 77mm (width) × 13.6mm (height); · 6.34 inches (length) × 3.03 inches (width) × 0.54 inches (height) |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports up to 1TB |
| notify | Alert sound; vibration (tactile feedback); multi-color LED light indication |
| keyboard | On-screen keyboard |
| Audio | Built-in single speaker (2W); two microphones with noise reduction function; supports Type-C headphones |
| Image acquisition | Front 8 million pixels; rear 16 million pixels (auto focus) |
| radio frequency band | GSM Quad Band(850/900/1800/1900Mhz); WCDMA B1, B2, B5, B8; TDD-LTE B34, B38, B39, B40, B41; FDD-LTE B1, B3, B5, B7, B8, B20, B28; 5G N1, N3, N8, N28, N41, N78, N79; TDD NR supports 1T4R SRS; supports 5G downlink CA (in-band/inter-band) at least 2cc; supports VoNR; supports PC2 power level; supports dedicated network (LTE/5G) |
| data rate | 5 GHz: 802.11a/n/ac/ax——20 MHz, 40 MHz, 80 MHz, 160MHz · 2.4 GHz: 802.11b/g/n/ax——20 MHz, 40 MHz · 2.4G+5G concurrency, the theoretical rate supports up to 3.6Gbps data rate |
| working channel | Depends on the country (region), 2.4GHz is 2.412GHz-2.472GHz; 5GHz is 5.18GHz-5.825GHz |
| Security and encryption | Security mode: legacy3/WPA/WPA2/802.1X; Encryption: WEP40/WEP104, TKIP and AES; Authentication: TTLS (TTLS-CHAP/MSCHAP/MSCHAPv2/PAP or MD5); PEAP (TTLS/MSCHAPv2/GTC); LEAP; FAST (TTLS/MSCHAPv2/GTC); Others: Support IPv6 |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm scan handle, spare battery, cradle, protective case and MDM or application enrollment needs.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make CRUISE2 5G Pro part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
