SEUIC (Dongji) / Touch mobile terminals
CRUISE Ge2-M: Touch mobile terminals
CRUISE Ge2-M is listed in the touch mobile terminals portfolio for touch-first mobile data capture. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: touch-first warehouse, retail, logistics and field applications
- Memory
- 6GB+64GB、6GB+128GB（LPDDR4X+UFS）
- Display
- 5.5-inch display; 1440*720; typical brightness 450nit
- Scan |
- X3P (SR) one-dimensional/two-dimensional image scanning engine · X3PC (HD) one-dimensional/two-dimensional image scanning engine · X3PC (MR) one-dimensional/two-dimensional image scanning engine
- power supply
- Removable 4.4V 5000mAh lithium-ion rechargeable battery, 6000mAh lithium-ion rechargeable battery (optional)
- Sealing level |
- IP68 sealing level (including battery)
- network connection
- WWAN 4G，WLAN
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where CRUISE Ge2-M fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and logistics applications
- Retail inventory and store operations
- Field inspection and service
Key capabilities
- A full-touch mobile terminal entry; scan engine, network, OS and battery options require model-level confirmation.
- Portfolio fit: touch-first warehouse, retail, logistics and field applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 5.5-inch display; 1440*720; typical brightness 450nit |
|---|---|
| touch screen | Capacitive touch with more than 5 points; supports glove touch/wet hand operation/double-click to wake up |
| CPU | | MT8781, eight cores, 2.2GHz |
| operating system | | Android 14.0 |
| Memory | 6GB+64GB、6GB+128GB（LPDDR4X+UFS） |
| Operating temperature | | -20℃ to +55℃ / -4℉ to 131℉ |
| Storage temperature | | -40℃ to +70℃ / -40℉ to 158℉ (battery not included) |
| Electrostatic discharge (ESD) | | ±15kV air discharge, ±8kV direct discharge |
Data capture
| Interactive Sensor Technology | | Gravity sensor, light sensor, distance sensor |
|---|---|
| Scan | | X3P (SR) one-dimensional/two-dimensional image scanning engine · X3PC (HD) one-dimensional/two-dimensional image scanning engine · X3PC (MR) one-dimensional/two-dimensional image scanning engine |
| Near field communication (NFC) | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards) |
Connectivity
| SIM card | | Choose 2 from 3 card holders, support dual SIM card dual standby, Nano SIM card |
|---|---|
| network connection | WWAN 4G，WLAN |
| Interface/communication | Waterproof Type-C USB interface; supports USB2.0 and Type-C headsets; supports OTG; charging 10W, 18W (optional) |
| GPS | GPS+GLONASS+Beidou+Galileo, supports AGPS; single frequency L1 |
| Wireless connection | | IEEE 802.11a/b/g/n/ac (2.4G/5G dual-band WIFI) |
Power and physical
| weight | 274±5g (9.65±0.18oz) (excluding hand strap) |
|---|---|
| power supply | Removable 4.4V 5000mAh lithium-ion rechargeable battery, 6000mAh lithium-ion rechargeable battery (optional) |
| button | Volume up/down buttons; power button; two dedicated scan buttons; programmable button for push-to-talk or other purposes |
Environmental
| Humidity | | 5% to 95% RH without condensation |
|---|---|
| Sealing level | | IP68 sealing level (including battery) |
| Roll Specs | | Withstands 1,000 drops from 1.6 feet / 0.5 meters at room temperature without protective case |
| Drop specifications | | Withstands a 4.92 ft (1.5 m) drop to concrete, terminal only |
Other configuration
| size | 156.6mm (length) × 76mm (width) × 16.7mm (height) (excluding key caps and hand straps); · 6.16 inches (length) × 2.99 inches (width) × 0.66 inches (height) |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports up to 512GB |
| Notification | | Sound, vibration (tactile feedback), multi-color LED light indication |
| Keyboard | | On-screen keyboard |
| Audio | | Built-in single speaker (2W); two microphones with noise reduction function |
| Image acquisition | | Front 5 million pixels; rear 13 million pixels (auto focus); · 16 million pixels (optional) · LED flash can generate balanced white light; supports flashlight mode |
| radio frequency band | Eurasian frequency bands: GSM 850/900/1800/1900; CDMA1X BC0; WCDMA B1/B5/B8; TDD-LTE B34/B38/B39/B40/B41; FDD-LTE B1/B3/B5/B7/B8/B20/B28; supports in-band carrier aggregation; VoLTE |
| data rate | 2.4GHz: 802.11b/g/n, 2.412GHz-2.472GHz, up to 150Mbps; · 5GHz: 802.11a/n/ac, 5.17GHz-5.825GHz, up to 433Mbps |
| Work channel | | Channel 1–13 (2412–2472MHz); Channel 36–165 (5180–5825MHz) |
| Security and Encryption | | OPEN, WEP, WPA2-PSK(TKIP+AES), TLS, TTLS(MS-CHAP), TTLS(MS-CHAPV2), TTLS(CHAP), TTLSMD5, TTLS-PAP, PEAP-TLS, PEAP(MS-CHAPV2), AES, etc. |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm scan handle, spare battery, cradle, protective case and MDM or application enrollment needs.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make CRUISE Ge2-M part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
