SEUIC (Dongji) / Barcode scanners
HS325DP: Barcode scanners
SEUIC (Dongji) HS325DP is a wireless DPM barcode scanner for distorted, curved and perforated marks. The official page lists adaptive red, white and blue lighting, a 1080 x 1280 global-shutter sensor, removable battery, 5000-record batch storage, USB or RS-232 host modes and an open-air radio range reference.
Suggested profiles: wireless DPM, production, quality and industrial traceability capture
- Scan angle
- Pitch +/-60 degrees and skew +/-55 degrees
- Battery
- 3150 mAh rated and 3500 mAh typical removable battery
- Protection
- IP54; manufacturer lists 50 drops from 1.8 m and 2000 tumbles at 0.5 m
- Wireless range
- Minimum 100 m direct line of sight in open air listed by the manufacturer
- Dimensions
- 166.2 x 68.5 x 105.5 mm; base dimensions vary in a second manufacturer configuration block
- Image sensor
- 1080 x 1280 CMOS global-shutter sensor
The exact model, regional configuration and commercial terms require project confirmation.
Browse by device capability
HS325DP / Browse by device capability
UROVO is the primary established product resource, with SEUIC (Dongji) and selected platforms used where the capture method, form factor or deployment requirement needs another option. Published models follow an evidence, regional-configuration and RuggedLayer validation path.
Suggested profiles
- Mobile production and quality inspection
- Automotive and electronics traceability
- Warehouse or line-side stations with difficult DPM codes
Browse by device capability
- Wireless DPM scanner format supports operator movement around production and quality stations.
- Adaptive RGB lighting, global-shutter capture and DPM optics target difficult industrial marks.
- Batch storage and removable power provide a defined offline workflow to validate with the host system.
- The open-air radio range and read-rate statements are manufacturer references, not a site result.
How a device enters the portfolio
Key specifications
Manufacturer-listed configuration; confirm the exact variant before ordering.
Platform
| Frame rate | 60 fps |
|---|---|
| Host interfaces | RS-232, USB keyboard and USB COM |
| Batch storage | Up to 5000 records listed |
Data capture
| Image sensor | 1080 x 1280 CMOS global-shutter sensor |
|---|---|
| Scan angle | Pitch +/-60 degrees and skew +/-55 degrees |
Connectivity
| Wireless range | Minimum 100 m direct line of sight in open air listed by the manufacturer |
|---|
Power and physical
| Dimensions | 166.2 x 68.5 x 105.5 mm; base dimensions vary in a second manufacturer configuration block |
|---|---|
| Weight | 226 g +/-3 g in the main scanner configuration listed |
| Battery | 3150 mAh rated and 3500 mAh typical removable battery |
| Charge time | 6-8 hours over USB or 2.5 hours over external 5 V power listed |
Environmental
| Protection | IP54; manufacturer lists 50 drops from 1.8 m and 2000 tumbles at 0.5 m |
|---|---|
| Environment | Operating 0-50 C; storage -20 to +70 C; 5-95% RH non-condensing |
Other configuration
| Lighting and aimer | Adjustable red, white and blue diffuse lighting with cross-shape laser aimer |
|---|---|
| Decode scope | 1D and 2D families including UPC/EAN, Code 128, GS1-128, Code 39, Data Matrix, QR and PDF417 |
| Decode density | 1D codes to 3 mil; 2D codes to 5 mil listed |
| Regulatory listing | CE, FCC, RoHS and UN38.3 are listed on the manufacturer page; verify exact SKU and destination evidence |
A final shortlist depends on the application, scan or RFID workload, operating environment, country, deployment volume and support expectations.
A clear handoff at every layer
Five service layers for a more predictable device program.
RuggedLayer organizes access to multiple manufacturers into a consistent engagement model. Each layer has a defined input, deliverable and evidence boundary.
Service layers
- Confirm the wireless region, pairing mode, battery, DPM optics, host protocol and charging arrangement before ordering.
- Test code quality, lighting, radio interference, roaming, batch queue, duplicate handling and reconnect at the target site.
- Resolve the multiple physical configuration blocks on the source page against the exact SKU before fixing mounts or accessories.
Deployment accessories
- Scope the charging base or USB power, spare batteries, stand, mounting equipment, cable and operator carry arrangement.
- Version the radio profile, DPM lighting setting, batch policy and approved code samples with the deployment handover.
RuggedLayer Test Lab
Define a useful test, not a vague benchmark.
Tell us the labels, tags, application and operating conditions that matter.
- 01
Measure first-pass reads and false or duplicate reads for the full target mark set at line speed.
- 02
Test wireless range, host reconnect, batch upload, battery turnaround, feedback and offline recovery.
- 03
Record the exact physical configuration, optics, firmware, radio, accessories, compliance evidence and acceptance limits.
