SEUIC (Dongji) / Barcode scanners
HS305DP: Barcode scanners
SEUIC (Dongji) HS305DP is a wired DPM barcode scanner for distorted, curved, dot-peen, blurred and low-contrast marks. The official page lists a global-shutter 1280 x 1080 sensor, adaptive red, white and blue diffuse lighting, 60 fps capture, USB or RS-232 modes, IP54 and a 1.8 m drop specification.
Suggested profiles: wired DPM, manufacturing traceability and difficult-code stations
- Scan angle
- Pitch +/-60 degrees and skew +/-55 degrees
- Protection
- IP54; industrial plastic housing listed
- Dimensions
- 166.2 x 68.5 x 105.5 mm
- Image sensor
- 1280 x 1080 CMOS global-shutter sensor
- Lighting and aimer
- Adjustable red, white and blue diffuse lighting with cross-shape laser aimer
- Frame rate
- 60 fps
The exact model, regional configuration and commercial terms require project confirmation.
Browse by device capability
HS305DP / Browse by device capability
UROVO is the primary established product resource, with SEUIC (Dongji) and selected platforms used where the capture method, form factor or deployment requirement needs another option. Published models follow an evidence, regional-configuration and RuggedLayer validation path.
Suggested profiles
- Automotive and electronics part marking
- Production and quality traceability stations
- Packaging or workstations handling curved and low-contrast marks
Browse by device capability
- DPM-focused wired scanner for traceability marks that challenge general-purpose imagers.
- Adaptive three-color diffuse lighting gives the integrator a concrete illumination profile to test.
- USB keyboard, USB COM and RS-232 modes keep the station host contract explicit.
- Readability claims require representative marks, surfaces, distance, angle and lighting validation.
How a device enters the portfolio
Key specifications
Manufacturer-listed configuration; confirm the exact variant before ordering.
Platform
| Frame rate | 60 fps |
|---|---|
| Host interfaces | RS-232, USB keyboard and USB COM |
Data capture
| Image sensor | 1280 x 1080 CMOS global-shutter sensor |
|---|---|
| Scan angle | Pitch +/-60 degrees and skew +/-55 degrees |
Power and physical
| Dimensions | 166.2 x 68.5 x 105.5 mm |
|---|---|
| Weight | 162 g +/-3 g |
Environmental
| Protection | IP54; industrial plastic housing listed |
|---|---|
| Drop and impact | Manufacturer lists 50 drops from 1.8 m and 2000 tumbles at 0.5 m |
| Environment | Operating 0-50 C; storage -20 to +70 C; 5-95% RH non-condensing |
Other configuration
| Lighting and aimer | Adjustable red, white and blue diffuse lighting with cross-shape laser aimer |
|---|---|
| Decode scope | 1D and 2D families including UPC/EAN, Code 128, GS1-128, Code 39, Data Matrix, QR and PDF417 |
| Decode density | 1D codes to 3 mil; 2D codes to 5 mil listed |
| Ambient light | 0-100,000 lux listed |
| ESD | Manufacturer lists +/-15 kV air and +/-8 kV direct discharge |
| Regulatory listing | CE, FCC and RoHS are listed on the manufacturer page; verify exact SKU and destination evidence |
A final shortlist depends on the application, scan or RFID workload, operating environment, country, deployment volume and support expectations.
A clear handoff at every layer
Five service layers for a more predictable device program.
RuggedLayer organizes access to multiple manufacturers into a consistent engagement model. Each layer has a defined input, deliverable and evidence boundary.
Service layers
- Fix the lighting colors, aimer, working distance, interface, mount and trigger behavior before the pilot.
- Test dot-peen, laser, curved, reflective, blurred, damaged and low-contrast marks at production speed.
- Verify host reconnect, cable routing, power budget, compliance evidence and maintenance access before rollout.
Deployment accessories
- Scope the stand, mount, USB or serial cable, power arrangement, lighting clearance and replacement cable plan.
- Keep approved DPM samples, lighting profile, host mode and cleaning instructions with the station handover.
RuggedLayer Test Lab
Define a useful test, not a vague benchmark.
Tell us the labels, tags, application and operating conditions that matter.
- 01
Measure first-pass, missed, duplicate and false reads across the target mark set and operating envelope.
- 02
Test trigger timing, USB/RS-232 data behavior, host latency, reconnect and exception recovery.
- 03
Record the scanner configuration, lighting, mount, firmware, cable, compliance evidence and acceptance result.
