SEUIC (Dongji) / Industrial tablets
AUTOID Pad Air: Industrial tablets
AUTOID Pad Air is listed in the industrial tablets portfolio for large-screen mobile work and operator guidance. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: large-screen warehouse, field, retail and industrial applications
- Memory
- 4GB memory/64GB flash memory; 8GB memory+128GB flash memory
- Display
- 10.1-inch full-viewing LCD display, 1920×1200, 400 nits; optional 4096-level pressure-sensitive screen
- Scan |
- X3 1D/2D advanced laser scanning engine
- Power |
- User-non-removable 10140mAh lithium-ion rechargeable battery
- Sealing level |
- IP65 sealing level (including battery)
- Interface/communication
- TYPE-C interface, supports USB3.0 (downwardly compatible with USB2.0), headphones, host charging, supports OTG
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID Pad Air fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and production dashboards
- Field inspection and work instructions
- Vehicle, cart or workstation deployments
Key capabilities
- A tablet platform for industrial applications; operating system, mounting, ports and environmental scope require confirmation.
- Portfolio fit: large-screen warehouse, field, retail and industrial applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 10.1-inch full-viewing LCD display, 1920×1200, 400 nits; optional 4096-level pressure-sensitive screen |
|---|---|
| Touch screen | | capacitive touch |
| CPU | | Qualcomm 662, 8-core 2.0GHz |
| operating system | | Android11 and Android14 |
| Memory | 4GB memory/64GB flash memory; 8GB memory+128GB flash memory |
| Operating temperature | | -10℃ to 50℃/14℉ to 122℉ |
| Storage temperature | | -20℃ to 60℃/-4℉ to 140℉ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
Data capture
| interactive sensor technology | Acceleration sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| Scan | | X3 1D/2D advanced laser scanning engine |
| Camera | 5 million pixels on the front; 13 million pixels on the rear (phase focus) |
| Near field communication (NFC) | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards); supports ID card reading |
| Scanning hand rest (optional) | | Scanning hand rest with rotatable hand strap, with a scanning button on the left and right sides of the hand rest |
Connectivity
| SIM card | | Nano SIM*1 |
|---|---|
| Interface/communication | TYPE-C interface, supports USB3.0 (downwardly compatible with USB2.0), headphones, host charging, supports OTG |
| GPS | | GPS+GLONASS+Beidou, support AGPS |
| WIFI | IEEE802.11 a/b/g/n/ac/ax ready (2.4G/5G dual-band WIFI), please refer to the product specification for details |
Power and physical
| weight | 660g / 23.28 oz (standard model, including battery) |
|---|---|
| Power | | User-non-removable 10140mAh lithium-ion rechargeable battery |
| button | | 3 buttons (power, volume +, -) |
Environmental
| Humidity | | 5% to 95% RH without condensation |
|---|---|
| Sealing level | | IP65 sealing level (including battery) |
| Drop specifications | | Withstands a drop to marble from 3.94 feet (1.2 meters) with terminal only; 2.62 feet (0.8 meters) with handrest |
Other configuration
| size | 10.16 inches (length) × 6.81 inches (width) × 0.46 inches (height) · 258 mm (length) × 173 mm (width) × 10.8 mm (height) |
|---|---|
| expansion slot | | User-accessible Micro SD Card, supports up to 256GB |
| Internet connection | | WWAN 4G、WLAN、WPAN |
| notify | Alert sound; multi-color LED; vibration (tactile feedback) |
| Keyboard | | On-screen keyboard |
| Audio | | Built-in stereo speakers, 4Ω2W*2; built-in dual microphones, supports TypeC digital headsets |
| Vibration resistance level | | YD/T 1539 |
| Fingerprint (optional) | | Supports living fingerprint collection, second-generation ID fingerprint module · Resolution: 508dpi, 256 grayscale |
| radio frequency band | | GSM：850/900/1800 · WCDMA：B1/B5/B8 · TDD-LTE：B34/B38/B39/B40/B41 · FDD-LTE：B1/B3/B5/B7/B8 |
| Warm reminder | | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Scope mounts, docks, vehicle power, protective equipment and keyboard or scanner integration with the final use case.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID Pad Air part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
